H-3566 Smart HMI Mainboard RK3566,quad-core Cortex-A55,Clock up to 1.8GHz Standard 8GB EMMC

  • 1
  • 2

Brand Name : Shi Zun

Model Number : H-3566 Mainboard

Place of Origin : China

MOQ : Negotiable

Price : Negotiable

Payment Terms : T/T

Supply Ability : 100+pcs+day

Packaging Details : 100mm* 90mm* 9mm

CPU : RK3566, quad-core Cortex-A55,Clock up to 1.8GHz

GPU : Mali-G52 2EE

NPU : Support 1Tops computing power

RAM : Standard 2GB LPDDR4, optional 4GB/8GB

ROM : Standard 8GB EMMC, up to 128GB Display

LVDS : 30Pin dual-channel LVDS interface, supporting up to 1080P resolution

HDMI : HDMI 2.0 interface, supporting up to 4K resolution

MIPI : 31Pin FPC MIP-DSI interface, supporting up to 1920x1200 resolution

eDP : Standard eDP interface, supporting up to 1080 resolution

Headphone : Four-stage 3.5mm headset socket, supports plugging headphones into the speaker to mute

Line Output : Standard left and right channel line output

MIC Input : Single-ended MIC input

Amplifier Output : 8 ohm·-6W dual- channel audio amplifier output

USB Host : 2 external USBs (USB 2.0*1, USB 3.0*1). 8 built-in USB2.0 (1 of which is CPU pass-through USB)

USB OTG : 1 USB2.0 OTG interface

TF Card : Self-elastic TF card socket, supports 128GB TF card

Serial ports : 4-way TTL/RS232 serial port, 1-way TTL/RS485 serial port

SATA hard drive : 1 standard SATA 3.0 hard disk interface (with power header)

RTC : Low power consumption RTC circuit with CR1220 battery

12C : 2-way I2C interface

Backlight : 1-way backlight control interface, supports switch and brightness adjustment

GPIO : 5-way GPIO signals

Infrared : Infrared receiving pin header

Button : Burn button and power button

Pilot lamp : Green work indicator light

Camera : 40Pin FPC binocular MIPI-CSI camera interface

POE : 1-way POE power receiving interface

Ethernet : 1-way 10/100/1000Mbps adaptive Ethernet

Wi-Fi : High-performance WiFi, supports 802.11 b/g/n/ac

Bluetooth : High-performance Bluetooth, Support BT V5.2

DC Input : 12V DC socket, supports 9V-15V wide voltage input

Size : 100mm* 90mm

Thickness : 9mm

Structure Compatibility : Compatible with H0、H3、H-3399、H-3566、H-T972 structure and interchangeable

Operating Temperature : -20℃~70℃

Humidity : 0%-95% (non-condensing)

Android system : Recommend Android 11.0

Linux System : Linux Buildroot/ Debian10/ Ubuntu 18.04 Optional

Harmony system : OpenHarmony 3.2 Optional

Contact Now

H-3566 Smart HMI Motherboard RK3566,quad-core Cortex-A55,Clock up to 1.8GHz Standard 8GB EMMC

H-3566 Smart HMI Motherboard Description:

H-3566 adopts Rockchip RK3566, quad-core Cortex-A55 architecture processor,clock up to 1.8GHz, built-in neural network NPU, supporting 1Tops computing power, 8GB large RAM optional , compact design, suitable for Small smart self-service terminals, face verification equipment, welcome robots, edge computing and other scenarios.

H-3566 Smart HMI Motherboard Parameters:

Keyword:

 Smart HMI Motherboard

CPU:

 RK3566,quad-core Cortex-A55,Clock up to 1.8GHz
GPU: Mali-G52 2EE NPU: Support 1Tops computing power

RAM:

 Standard 2GB LPDDR4, optional 4GB/8GB

ROM:

 Standard 8GB EMMC, up to 128GB

USB Host:

 2 external USBs (USB 2.0*1, USB 3.0*1). 8 built-in USB2.0 (1 of which is CPU pass-through USB)

Serial Port:

 4-way TTL/RS232 serial port, 1-way TTL/RS485 serial port
Headphone: Four-stage 3.5mm headset socket, supports plugging headphones into the speaker to mute HDMI: HDMI 2.0 interface, supporting up to 4K resolution
MIPI: 31Pin FPC MIP-DSIinterface, supporting up to 1920x1200 resolution MIC Input: Single-ended MIC input
Pilot lamp: Green work indicator light USB OTG: 1 USB2.0 OTG interface

Bluetooth:

 High-performance Bluetooth, Support BT V5.2

Android:

 Recommend Android 11.0

H-3566 Smart HMI Motherboard Features:

  1. Processor: A powerful Rockchip RK3566 quad-core Cortex-A55 processor, offering high performance for various HMI applications.

  2. Graphics: Integrated GPU capable of supporting high-resolution displays and providing smooth graphics for UI interactions.

  3. Display Outputs: Multiple display output options, such as HDMI, LVDS, or eDP, to connect to various types of screens.

  4. Memory: Support for DDR4 RAM, allowing for fast and efficient operation, with options for different capacities to suit various needs.

  5. Storage: Onboard eMMC storage for the operating system and applications, with options for different sizes.

  6. Connectivity: Gigabit Ethernet for wired network connectivity, Wi-Fi, and Bluetooth for wireless communication.

  7. USB Ports: Multiple USB ports for connecting peripherals such as keyboards, mice, barcode scanners, or other input/output devices.

  8. Expansion Slots: Possibly mini PCIe or M.2 slots for additional expansion, such as adding a 4G/5G module or an additional Wi-Fi card.

  9. I/O Interfaces: RS-232 and RS-485 serial ports for industrial communication, along with GPIO pins for custom interfacing.

  10. Operating System Support: Support for various operating systems, including Linux and Android, tailored for HMI applications.

  11. Industrial-Grade Design: Designed to withstand harsh environments, with wide temperature range support and robust construction.

  12. Power Management: Efficient power management features to ensure low power consumption and long-term reliability.

  13. Security Features: Potential support for hardware-based security features, such as TPM, for secure boot and data protection.

  14. Certifications: Compliance with industry standards and certifications, such as CE, FCC, and UL, ensuring safety and reliability.

  15. Customization: Options for customization to meet specific application requirements, such as specific I/O configurations or additional processing capabilities.
